最大鉆孔深度m

Maximum drilling depth.(m)

30

最大鉆孔直徑mm

Maximum drilling diameter .(mm)

3000

發動機額定功率KW/rpm

Engine rated power.(KW/rpm)

184

行走驅動

四驅

動力頭最大扭矩kN.m

Maximum torque of power head.(KN.m)

120

動力頭轉速rpm

Power head speed.(rpm)

10-50

液壓系統最大工作壓力主泵MPa

Maximum working pressure of hydraulic system main pump.(MPa)

31.5

液壓系統最大流量主泵L/min

Maximum bow rate of the main pump hydraulic system.(L/min)

120

加壓系統最大加壓力KN

Maximum pressurization force of the pressurization system(KN)

100

加壓系統最大提升力KN

Maximum lifting force of the pressurization system(KN)

80

加壓系統最大行程m

Maximum stroke of the pressurization system(m)

2.5

主卷?yè)P(yáng)最大提升力KN

Maximum lifting force of the main winch.(KN)

12

主卷?yè)P(yáng)最大提升速度m/min

Maximum lifting speed of the main winch(m/min)

50

副卷?yè)P(yáng)最大提升力KN

Maximum lifting force of the auxiliary winch.(KN)

1.5

副卷?yè)P(yáng)最大提升速度m/min

Maximum lifting speed of auxiliary winch(m/min)

50

鉆桅左右傾角°

Left and right inclination angle of drilling mast(°)

±5

鉆桅前傾角°

Forward and backward inclination angle of the drilling mast. (°)

±5

工作狀態寬度mm

Overall width of working state.(mm)

3500

運輸狀態長度mm

Overall length of transport status.(mm)

10100

運輸狀態寬度mm

Overall width of transport status.(mm)

3000

運輸狀態高度mm

Overall height of transport status.(mm)

3750
